Description
$4.37
Description
Quick Specs | |
---|---|
Catalog Number | 1877VB0X |
Vendor Code | EWD |
Manufacturer | Eaton |
Manufacturer’s Part Number | 1877V-BOX |
Description | Recp Single 20A 125V 2P3W Swire Iv |
Categories | |
Category | Wiring Devices – Consumer PKGD Wiring Devices |
Classification | Commercial Receptacles |
UNSPSC | 39121406 – Electrical receptacles |
Identification | |
UPC/GTIN | 032664184406 / 00032664184406 |
GTIN | 00032664184406 |
UPC | 032664184406 |
Price & Packaging | |
Minimum Order Quantity | 1 |
Unit Price | $4.37 (Each) |
Carton Price | $43.70 (Per 10) |
Standard Packaging | $437.00 (Per 100) |
Stock Availability | |
Nacogdoches | 2 |
All Stores | 1,884 |
Features | |
Number of Gangs | 1 |
Current Rating | 20 A |
Voltage Rating | 125 V AC |
Wire Size | #10 AWG |
Material | Thermoplastic |
Material, Color, and Finish | |
Color | Ivory |
Dimensions and Weight | |
Width | 1.32 in (33.5 mm) |
Height | 3.81 in (96.8 mm) |
Thickness | 0.82 in (20.8 mm) |
Weight | 0.164 lbs |
Descriptions | |
Product Type | Single Receptacle |
Short Description | Single Receptacle, 2 Pole, 1 Gang, 20 A, 125VAC |
Long Description | Single Receptacle, 2 Poles, 1 Gang, 3 Wires, 20 A, 125 V AC, 1.32 in (W) x 3.81 in (H), 0.82 in Thickness, Thermoplastic, Ivory, #10 AWG, -20 °C to +60 °C, Impact and Chemical Resistant, Tamper Resistant |
Extra Long Description | EWD 1877V-BOX Recp Single 20A 125V |
Special Features | Heavy Duty Grade; Enhanced Ground Contacts; Tamper Resistant |
Environmental and Standards | |
Minimum Operating Temperature | -20 °C |
Maximum Operating Temperature | +60 °C |
Resistance Properties | Impact and Chemical Resistant; Tamper Resistant |
Standards Met | cULus Listed, CSA C22.2 No. 42, NOM Certified, UL498, NAFTA, RoHS Compliant |
Manufacturer Information | |
Brand | Arrow Hart |
Manufacturer’s Part Number | 1877V-BOX |
Taxonomies, Classifications, and Categories | |
Type | Commercial Specification Grade |
Category Description | Commercial Receptacles |
Packaging | |
Package Quantity | 1 ct |
Carton | 10 |
Package | 100 |
Uses & Applications | |
Application | Commercial |
NEMA Rating | 5-20R |
