89206 – Terminal Strip, 6-Pole, 22-10 Awg
$
(per )
(Each)
$20.79
(Each)
$
(per 1)
Availability:
In Stock Locally
| Specification | NSI AS-K1-K1 | Ideal 89-206 |
|---|---|---|
| Type | Power Distribution Block | Terminal Strip |
| Poles / Circuits | 1 Primary / 1 Secondary Opening | 6 Circuits / 6 Poles |
| Wire Size | #14 to 2/0 AWG (Line & Load) | 22–10 AWG |
| Current Rating | 175 Amps | 30 Amps |
| Voltage Rating | 600 V | 600 V AC |
| Material (Body) | Glass-Filled Polyester | Polyester Thermoplastic (UL 94V-0) |
| Material (Conductive) | Aluminum/Copper | Steel (Screws) |
| Cover Type | Clear Acrylic | Optional |
| Temperature Range | Max +90°C | -40 to +130°C (260°F) |
| Dimensions (L x W x H) | 2.9″ x 1.04″ x 2.34″ | 4.37″ x 1.33″ x 0.81″ |
| Weight | 0.58 lbs | 0.22 lbs |
| Mounting | 2 Mounting Holes | Surface Mount |
| Certifications | UL, CSA | UL Recognized, CSA Certified, RoHS |
| Catalog Number | ASK1K1 | 89206 |
| Manufacturer | NSI Industries | Ideal Industries |
| Unit Price | $24.71 (Each) | $20.79 (Each) |
| Package Price | $74.13 (Pack of 3) | N/A |
| Use Case | High-current, compact power distribution | General low-power terminal connections |
