(Each)
$34.19
(Each)
(per 1)
(per 5)
In Stock Locally
$34.19
| Specification | Details |
|---|---|
| Catalog Number | 89210 |
| Vendor Code | IDE |
| Manufacturer | Ideal |
| Manufacturer’s Part Number | 89-210 |
| Description | Terminal Strip, 10-Pole, 22-10 AWG |
| Long Description | Terminal Strip, 10 Circuits, 10 Poles, 30 A, 600 V AC, Steel (Screw) Material, -40 to +260 °F, 6.62 in Length, 1.33 in Width, 0.81 in Height, 0.37 lb |
| Short Description | Terminal Strip, 10 Circuits, 10 Poles |
| Special Features | – Torque Rating: 16 in-lbs – Rugged polyester thermoplastic base (UL 94V-0) – Corrosion resistant screws & surface plates – Accepts up to #10 AWG wire – Center spacing: 0.562 in (14.3 mm) – Accessory jumpers & hardware available – Optional cover to prevent contact with live terminals |
| Categories | Accy, Fuseholders & Fuseblocks – Power BLKS & Distribution BLKS |
| Classification | Terminal Block Accessories |
| UNSPSC | 39121407 – Terminal strips |
| UPC/EAN/GTIN | 783250892105 / 0783250892105 / 00783250892105 |
| Weight per unit | 0.37 lbs |
| Price & Packaging | Unit Price: $34.19 Standard Packaging: $170.95 (Per 5) |
| Stock Availability | Nacogdoches: 20 All Stores: 68 |
| Electrical Ratings | Current Rating: 30 A Voltage Rating: 600 V AC |
| Material | Steel (Screw), Polyester thermoplastic base |
| Wire Size | 22 – 10 AWG |
| Dimensions | Length: 6.62 in Width: 1.33 in Height: 0.81 in |
| Operating Temperature | -40 to +130 °C (-40 to +260 °F) |
| Standards Met | CSA Certified LR15364 UL Recognized E82048 RoHS |
| Country of Origin | Made in USA |
| Package Quantity | 1 count |
