(Each)
$196.95
(Each)
(per 1)
(per 4)
In Stock Locally
$196.95
| Quick Specs | |
| Catalog Number | A10086CH Vendor Code HOF |
| Manufacturer | Nvent Hoffman |
| Manufacturer’s Part Number | A10086CH |
| Description | 10X8X6 N12 CH, SCDN LTCH |
| Details | Junction Box, Steel, Type 12 Continuous Hinge, Bracket Mount, Gray, Polyester Powder Paint, 8 In Overall Width, 10 In Overall Length, 6 In Overall Height, 10.5 LB |
| Categories | Metal Enclosures & Cabinets – Nema Types 12 & 13 Metallic En |
| Classification | Steel Junction Boxes |
| UNSPSC | 39121303 – Electrical boxes |
| UPC/GTIN | 783510548704 / 00783510548704 |
| Weight per unit | 10.5 (lbs/each) |
| Price & Packaging | |
| Minimum Order Quantity | 1 |
| Unit | $196.95 (Each) |
| Standard Packaging | $787.80 (Per 4) |
| Features | |
| Material | Steel |
| Cover Type | Type 12 Continuous Hinge |
| Mounting Type | Bracket Mount |
| Color | Gray |
| Color Code | ANSI 61 |
| Finish | Polyester Powder Paint |
| IP Rating | IP65 |
| Special Features | Continuously Welded and Ground Smooth Continuous Hinge; Screw-Down Door Clamps; Bonding Provision on Door; External Welded-On Mounting Brackets for Easy Installation; Oil-Resistant Gasket; Weldnuts Provided for Mounting Option |
| Features | This easy-to-open, continuous hinge enclosure features screw-down clamps for secure closure and can be used in a wide variety of applications. |
| Descriptions | |
| Product Type | Junction Box |
| Short Description | 8X8X4 N12 Junction Box, Steel, Gray |
| Long Description | Junction Box, Steel, Type 12 Continuous Hinge, Bracket Mount, Gray, Polyester Powder Paint, 8 in Overall Width, 10 in Overall Length, 6 in Overall Height, 10.5 lb |
| Extra Long Description | NVENT HOF A10086CH CH Box 10.00×8.0 |
| Dimensions | 10.00 x 8.00 x 6.00 in |
| Overall Length | 10 in; 254 mm |
| Overall Width | 8 in; 203 mm |
| Overall Height | 6 in; 152 mm |
| Manufacturer Information | |
| Brand | Nvent Hoffman |
| GTIN | 00783510548704 |
| UPC | 783510548704 |
| Taxonomies, Classifications, and Categories | |
| Type | Mild Steel Industrial Terminal and Junction Boxes |
| Category Description | Steel Junction Boxes |
| Packaging | |
| Weight | 10.5 lb |
| Weight per each | 10.5 |
| Carton | 1 |
| Package | 4 |
| Uses, Certifications, and Standards | |
| Application | This Easy-To-Open Continuous Hinge Enclosure Features Screw-Down Clamps for Secure Closure |
| Standards Met | UL 50, 50E Listed, TYPE 12, 13, FILE NO. E27567; cUL Listed per CSA 22.2 NO. 94, Type 12, 13, FILE NO. E27567; UL 508A Listed, Type 12, 13, FILE NO. E61997; cUL Listed per CSA 22.2 NO. 94, Type 12, 13, FILE NO. E61997 |
| Made in USA | Yes |
