A202008LP – 20X20X8 N12 CH XLMP CVR
$
(per )
(Each)
$739.39
(Each)
$
(per 1)
Availability:
In Stock Locally
| Nvent Hoffman A202008LP Wall-Mount Enclosure Specifications | |
|---|---|
| Catalog Number | A202008LP |
| Vendor Code | HOF |
| Manufacturer | Nvent Hoffman |
| Manufacturer’s Part Number | A202008LP |
| Description | 20X20X8 N12 CH XLMP CVR |
| Long Description | Wall-Mount Enclosure, Steel, Type 12 Continuous Hinge, White (Inside); ANSI 61 Gray (Outside), 20 in Overall Width, 20 in Overall Length, 8 in Overall Height, 32.04 lb |
| Short Description | 20x20x8 Wall-Mount Enclosure, Steel, White (Inside); ANSI 61 Gray (Outside) |
| Extra Long Description | NVENT HOF A202008LP Enclosure 20.00 |
| Classification & Categories | |
| Category | Metal Enclosures & Cabinets – NEMA Types 12 & 13 Metallic En |
| Classification | Steel Junction Boxes |
| UNSPSC | 39121324 – Electrical general purpose enclosure |
| Material, Color, and Finish | |
| Material | Steel |
| Cover Type | Type 12 Continuous Hinge |
| Finish | Powder Coated |
| Color | White (Inside); ANSI 61 Gray (Outside) |
| Dimensions & Weight | |
| Overall Length | 20 in (508 mm) |
| Overall Width | 20 in (508 mm) |
| Overall Height | 8 in (203 mm) |
| Depth | 8 in |
| Size | 20.00 x 20.00 x 8.00 in |
| Weight | 32.04 lbs |
| Price & Packaging | |
| Minimum Order Quantity | 1 |
| Unit Price | $739.39 (Each) |
| Carton Quantity | 1 |
| Additional Information | |
| Product Type | Wall-Mount Enclosure |
| Mounting Type | Wall Mount |
| Enclosure Type | NEMA 12/13 |
| IP Rating | IP65 |
| NEMA Rating | 12 Indoor, dust-resistant |
| Special Features | Continuously welded and ground smooth external wall-mounting brackets; formed external return flanges; screw-down door clamps; padlocking hasp |
| Features | Bright white interior for increased control visibility, secure closure with screw-down clamps |
| Certifications & Standards | |
| Standards Met | UL 508A Listed, cUL Listed, CSA Certified |
| Made in USA | Yes |
| Manufacturer Information | |
| Brand | Nvent Hoffman |
| GTIN | 00783510281700 |
| UPC | 783510281700 |
