(Each)
$2.28
(Each)
(per 1)
In Stock Locally
$2.28
| Attribute | Value |
|---|---|
| Catalog Number | B2209PA34 |
| Vendor Code | BLI |
| Manufacturer | Eaton |
| Manufacturer’s Part Number | B2209PA ZN |
| Brand | Eaton |
| Sub Brand | Bolted Framing |
| Description | BLTF 3/4″ ZINC PLATE PRE-ASSEMBLED UNV PIPE CLAMP |
| Short Description | Pre-Assembled Pipe Clamp, Low-Carbon Steel, Zinc Plated, 3/4 in; 20 mm |
| Long Description | Pre-Assembled Pipe Clamp, Low Carbon Steel, Zinc Plated, 14 ga Thickness, 3/4 in Size, 400 lb (Design Load 1); 50 lb (Design Load 2, 3) Capacity, 12 lb |
| Extra Long Description | B-LINE B2209PAZN 3/4″-MULTI-GRIP PIPE CLAMP |
| Product Type | Pre-Assembled Pipe Clamp |
| Type | Multi-grip and Offset Pipe Clamp |
| Material | Low Carbon Steel |
| Finish | Zinc Plated |
| Size | 3/4 in; 20 mm |
| Thickness | 14 ga; 1.9 mm |
| Weight per Unit | 0.12 lbs |
| Total Weight | 12 lbs (5.4 kg) |
| Dimensions | 2.375 in x 1.250 in x 0.0677 in |
| Construction | Two Piece |
| Pipe Range | 0.917 to 1.081 in OD |
| Capacity | 400 lb (1.78 kN) Vertical, 50 lb (0.22 kN) Transverse |
| Application | Strut System |
| Mounting | Channel |
| Features | Includes Combination Recess Hex Head Machine Screw and Square Nut |
| Special Features | Multi-grip; Pre-assembled; For use with EMT, IMC, Rigid conduit/pipe |
| UPC | 781011604240 |
| GTIN | 00781011604240 |
| UNSPSC | 39121311 – Electrical fittings |
| Category Description | Beam, RA, Edge, & Parallel Clamps |
| Status | Inactive |
| Packaging | 1 CT; 100 PK |
| Standard | Not Applicable |
