Catalog Number: BRP40B200
Manufacturer: Eaton
Manufacturer Part Number: BRP40B200
UPC/GTIN: 786689044053 / 00786689044053
Weight: 36 lbs
| Attribute | Value |
|---|---|
| Type | Main Breaker Loadcenter |
| Series | BR Plug-On Neutral (PON) |
| Amperage Rating | 200 A |
| Voltage Rating | 120/240 V |
| Phase | Single-Phase (1-Phase) |
| Interrupt Rating | 25 kAIC |
| Spaces | 40 |
| Circuits | 80 |
| Breaker Type | Type BR 1-inch breakers |
| Cover | Included |
| Mounting | Combination Mount |
| NEMA Rating | NEMA 1 (Indoor) |
| Enclosure Material | Metallic |
| Bus Material | Aluminum |
| Service Type | Main or Subpanel |
| Dimensions (H x W x D) | 3.88″ x 15.5″ x 39″ |
| Special Features | Includes BREQS125 hold-down screw and ground bar |
$334.90 each
Minimum Order Quantity: 1
Packaging: 1 unit per carton
Short Description:
BR PON Loadcenter 200A 25KAIC MCB, 40/80 Circuits, Aluminum Bus
Marketing Description:
Eaton’s BRP40B200 Plug-On Neutral Loadcenter is a 200A main breaker panel designed for residential and light commercial applications. It features 40 spaces supporting up to 80 circuits, a rugged aluminum bus, and a NEMA 1 indoor metallic enclosure. The unit comes complete with a BREQS125 hold-down screw and pre-installed ground bar for fast, secure installation.
