(Each)
$196.33
(Each)
(per 1)
In Stock Locally
$196.33
| Field | Value |
|---|---|
| Catalog Number | CH12L3125B |
| Vendor Code | CHD |
| Manufacturer | Eaton |
| Manufacturer’s Part Number | CH12L3125B |
| Description | 3PH/CH Loadcntr 125A Mlo 12 Cir. Cu Bus Nema 1 |
| Detailed Description | Eaton CH Main Lug Loadcenter, Main Lug Only, 125 A, B, Copper, Nema 1, Metallic, Top/Bottom, CH, 12 Circuits, 12 Spaces, Four-Wire, Three-Phase, #1-4/0 Awg |
| Categories | Load Centers & Accessories – Three Phase Main Lug Load Cent |
| Classification | Loadcenters & Covers |
| UNSPSC | 39121101 – Load centers |
| UPC/GTIN | 782113097350 / 00782113097350 |
| Weight per unit | 11.1 (lbs/each) |
| Minimum Order Quantity | 1 |
| Unit Price | $196.33 (Each) |
| Amperage Rating | 125 |
| Phase | 3 |
| Interrupt Rating | 35 |
| Width | 14.3 |
| Height | 16.75 |
| Depth | 3.9 |
| Size | B |
| Product Type | 3PH/CH LC 125A Mlo 12 CKT Cu Bus Nema 1 |
| Extra Long Description | ETN CH12L3125B 3Ph/CH LC 125A MLO 1 |
| Features | Eaton’s CH 3/4-inch loadcenters enclose CH circuit breakers for power distribution and circuit protection in residential and light commercial applications. Also called a breaker box, electrical box or even a fuse box, the main function is to take electricity supplied by the utility and distribute it throughout the home to feed lights and receptacles. Covers are typically packaged separately and available as surface or flush mount. |
| Long Description | Eaton CH main lug loadcenter,Main lug only,125 A,B,Copper,NEMA 1,Metallic,Top/bottom,CH,12 Circuits,12 Spaces,Four-wire,Three-phase,#1-4/0 AWG |
| Media | Yes |
| Number of Spaces | 12 |
| Brand | EATON CUTLER-HAMMER |
| GTIN | 00782113097350 |
| UPC | 782113097350 |
| Category Description | LOADCENTERS & COVERS |
| Type | Main lug loadcenter |
| Weight per each | 11.1 |
| Carton | 1 |
| Application | Elec Assemblies, Panels & EOEM – Electrical Assemblies, Panels and EOEMs |
| Standard | UL 50, UL 67 |
