(Each)
$64.03
(Each)
(per 1)
In Stock Locally
$64.03
| Field | Value |
|---|---|
| Catalog Number | CH4L125FP |
| Vendor Code | CHD |
| Manufacturer | Eaton |
| Manufacturer’s Part Number | CH4L125FP |
| Description | 1 PH/CH Loadcntr 125A Mlo 4/8 Cir. Cu Bus Flush CO |
| Long Description | Eaton CH main lug loadcenters, Standard, Main lug only, 125A, 7, Copper, NEMA 1, Metallic, Top/bottom, CH, Flush, 2, Eight-pole, 4, Three-wire, Single-phase, 120/240 V, #14-1/0 AWG |
| Extra Long Description | ETN CH4L125FP 1 Ph/CH LC 125A MLO 4 |
| Product Type | 1 PH/CH LC 125A Mlo 4SP, Cu Bus FLSH CVR |
| Categories | Load Centers & Accessories – Single Phase Main Lug Load Cen |
| Classification | Loadcenters & Covers |
| UNSPSC | 39121101 – Load centers |
| UPC/GTIN | 782114190494 / 00782114190494 |
| Weight per unit | 9.8 (lbs/each) |
| Minimum Order Quantity | 1 |
| Unit Price | $64.03 (Each) |
| Phase | 1 |
| Voltage Rating | 120/240 V |
| Amperage Rating | 125 |
| Interrupt Rating | 25 |
| Wattage | Eight-pole |
| Width | 11 |
| Depth | 13 |
| Height | 3.69 |
| Size | 7 |
| Short Description | 1 PH/CH LOADCNTR 125A MLO 4/8 CIR. CU BUS FLUSH CO |
| Special Features | Standard |
| Features | Eaton’s CH 3/4-inch loadcenters enclose CH circuit breakers for power distribution and circuit protection in residential and light commercial applications. Also called a breaker box, electrical box or even a fuse box, the main function is to take electricity supplied by the utility and distribute it throughout the home to feed lights and receptacles. Covers are typically packaged separately and available as surface or flush mount. |
| Number of Spaces | 4 |
| Media | Yes |
| Mounting | Flush Mount |
| Brand | EATON CUTLER-HAMMER |
| GTIN | 00782114190494 |
| UPC | 782114190494 |
| Category Description | LOADCENTERS & COVERS |
| Type | Main lug loadcenter |
| Weight per each | 9.8 |
| Carton | 1 |
| Application | Elec Assemblies, Panels & EOEM – Electrical Assemblies, Panels and EOEMs |
| Standard | UL 67, UL 50 |
