| Field | Value |
|---|---|
| Catalog Number | CH4L125RP |
| Vendor Code | CHD |
| Manufacturer | Eaton |
| Manufacturer’s Part Number | CH4L125RP |
| Description | 1PH/CH Loadcenter 125A Mlo 4/8 Cir. Cu Bus Nema 3 |
| Long Description | Main Lug Load Center, 4 Spaces, 4 Circuits, 125 A, 120/240 V ac, #14 to 1/0 AWG Wire Size, Metallic Material, Copper Bus Material, 11 in Overall Length, 3.69 in Overall Width, 13 in Overall Height, 10.96 lb |
| Extra Long Description | ETN CH4L125RP 1 Ph/CH LC 125A MLO 4 |
| Product Type | Main Lug Load Center |
| Short Description | NEMA 3R Main Lug Load Center, 4/4 C, 125 A |
| Categories | Load Centers & Accessories – Single Phase Main Lug Load Cen |
| Classification | Loadcenters & Covers |
| UNSPSC | 39121101 – Load centers |
| UPC/GTIN | 782114190517 / 00782114190517 |
| Weight per unit | 10.96 (lbs/each) |
| Minimum Order Quantity | 1 |
| Unit Price | $98.17 (Each) |
| Phase | 1 |
| Voltage Rating | 120/240 V ac |
| Amperage Rating | 125 |
| Interrupt Rating | 25 |
| Wattage | Eight-pole |
| Wire Size | #14 to 1/0 AWG |
| Material | Metallic |
| Bus Material | Copper |
| Overall Length | 11 in; 279.4 mm |
| Width | 11 |
| Depth | 13 |
| Height | 3.69 |
| Size | 7r |
| Number of Circuits | 4 |
| Number of Spaces | 4 |
| Enclosure Type | Nema 3R |
| For Use With | Type CH Breakers |
| Circuit Breaker Compatibility | CH Circuit Breaker |
| Recommended Environment | Outdoor |
| Features | Loadcenters are enclosures specifically designed to house the branch circuit breakers and wiring required to distribute power to individual circuits. They contain either a main breaker when used at the service entrance point or a main lug when used as a sub-panel to add circuits to existing service. The main breaker protects the main entire panel and can be used as a service disconnect. The branch breakers protect the wires leading to individual electrical loads such as fixtures and outlets. |
| Special Features | Standard In |
| Media | Yes |
| Brand | EATON CUTLER-HAMMER |
| GTIN | 00782114190517 |
| UPC | 782114190517 |
| Category Description | LOADCENTERS & COVERS |
| Type | Main lug loadcenter |
| Weight | 10.96 lb |
| Carton | 1 |
| Application | Residential |
| Standards Met | UL 67 Listed; UL 50 Listed |
| Made in USA | Yes |
