(Each)
$19.59
(Each)
(per 1)
(per 10)
In Stock Locally
$19.59
| Field | Value |
|---|---|
| Catalog Number | CHQ130 |
| Vendor Code | CHD |
| Manufacturer | Eaton |
| Manufacturer’s Part Number | CHQ130 |
| Description | Type CHQ Classified BRKR 30A/1 Pole 120/240V 10K |
| Product Type | Standard Trip Circuit Breaker |
| Short Description | Standard Trip Circuit Breaker, 30 A, 120/240 VAC, Independent Tripping Mechanism |
| Long Description | Standard Trip Circuit Breaker, 30 A, Common Tripping Mechanism, Line and Load Lug Terminal, Plug-On, 120/240 V ac, 3 in Overall Height, 2.5 in Overall Length, 0.8 in Overall Width, 0.30 lb |
| Extra Long Description | ETN CHQ130 CHQ Classified 30A/1 Pol |
| Features | UL classified replacement, 15-year warranty, plug-on mounting, common trip, clamshell pack. |
| Special Features | Clamshell pack |
| Categories | Standard Trip Plug – 1 Pole Standard Trip Plug-In |
| Classification | Classified Breakers |
| UNSPSC | 39121603 – Miniature circuit breakers |
| UPC/GTIN | 782113010847 / 00782113010847 |
| Weight per Unit | 0.3 lbs |
| Minimum Order Quantity | 1 |
| Unit Price | $19.59 (Each) |
| Standard Packaging | $195.90 (Per 10) |
| Current Rating | 30 A |
| Voltage Rating | 120/240 V ac |
| Interrupt Rating | 10 kAIC |
| Poles | 1 |
| Tripping Mechanism | Common |
| Terminal Connection Type | Line and Load Lug |
| Mounting Type | Plug-On |
| Overall Height | 3 in |
| Overall Length | 2.5 in |
| Overall Width | 0.8 in |
| Dimensions | 2.5000 IN X 0.8000 IN X 3.0000 IN |
| For Use With | Type CH Loadcenters |
| Standards Met | UL 489 Listed; IGCC 4897 |
| Made in USA | Yes |
| Brand | Eaton Cutler-Hammer |
| Type | 3/4″ Thermal magnetic circuit breakers |
| Carton | 1 |
| Package | 10 |
| Applications | Renewable & Conventional Energy, Datacenters, Marine Vessels, Other |
