| Eaton DH362UDKW – 60A/3P HD Non-Fusible Safety Switch | |
|---|---|
| Catalog Number | DH362UDKW |
| Vendor Code | CHD |
| Manufacturer | Eaton Cutler-Hammer |
| Manufacturer’s Part Number | DH362UDKW |
| Short Description | Safety Switch, 60 A, 600 V dc |
| Long Description | Safety Switch, 60 A, 600 V dc, 3 Poles, 1/3 Phases, 3 Wires, Painted Galvanized Steel Enclosure, Non-Fusible, 8.76 in L x 10.22 in W x 14.14 in H, 17 lb |
| Extra Long Description | ETN DH362UDKW 60A/3P HD NF Wdw Sfty |
| Product Type | Safety Switch |
| Description | 60A/3P HD NF WINDOW SAFETY SWITCH 600V NEMA 12/3R |
| Category | Heavy Duty Safety Switches – Non-Fusible |
| Classification | Disconnects |
| UNSPSC | N/A |
| UPC / GTIN | 782114022719 / 00782114022719 |
| Amperage Rating | 60 A |
| Voltage Rating | 600 V DC |
| Number of Poles | 3 |
| Number of Phases | 1 or 3 |
| Number of Wires | 3 |
| Fusible/Non-Fusible | Non-Fusible |
| Material | Painted Galvanized Steel |
| Enclosure Type | NEMA 12 / 3R |
| Mounting | Surface Mount |
| Dimensions (L x W x H) | 8.76 in x 10.22 in x 14.14 in |
| Weight | 17 lb (7.718 kg) |
| Special Features | Upper Viewing Window; Triple Padlocking Capability; Mechanically Interlocked Door; Visible Double Break Quick-Make/Break Rotary Blade K-Switch Mechanism |
| Application | Power Distribution |
| Standards Met | UL98 Listed; UL 50 Listed; NEC 230.62 (C) Compliant Barrier |
| Made in USA | Yes |
| Media Available | Yes |
| Price | $1,844.23 (Each) |
| Minimum Order Quantity | 1 |
| Package Quantity | 1 Carton |
| Stock Availability |
|
