ECNR30 – 30A 250V Class RK5 Time Delay CL Fuse
$
(per )
(Each)
$17.59
(Each)
$
(per 10)
Availability:
In Stock Locally
| Attribute | Details |
|---|---|
| Catalog Number | ECNR30 Vendor Code EDN |
| Manufacturer | Edison |
| Manufacturer’s Part Number | ECNR30 |
| Description | 30A 250V Class RK5 Time Delay CL Fuse |
| Long Description | Time Delay Power Fuse, RK5 Class Fuse, Ferrule Fuse, 8 s @ 500% Response Time, Ferrule End x Ferrule End Connection, 30 A, 250 V AC; 125 V DC, Ferrule Terminal, 0.56 in Diameter, 2 in Overall Length, 0.50 lb |
| Short Description | Power Fuse, 30 A, 250 VAC/125 V DC, Time Delay, RK5 Class Duel Element |
| Extra Long Description | Class RK5 type; 2 inch; UL 248-12, CE, CSA C22.2 Approval; 250 VAC/125 VDC Voltage Rating; 0.56 inch diameter; 200,000 Amp (DC) Interrupting Rating; 30 Amp current rating; Ferrule Terminal Type; Dual Element, 10 Sec Time Delay Characteristics; Edison Brand; Application: General-purpose including lighting, heating, and other non-inductive load; ECNR Model |
| Slang Terms | — |
| Categories | Distribution Fuses – Dual Element |
| Classification | Fuses & Fuse Accessories |
| UNSPSC | 39121604 – Time delay fuses |
| UPC/GTIN | 782634507345 / 00782634507345 |
| Weight per Unit | 0.05 lbs/each |
| Packaging – Carton | 10 |
| Weight (Carton) | 0.50 lb; 0.23 kg |
| Minimum Order Quantity | 1 |
| Unit Price | $17.59 (Each) |
| Carton Price | $175.90 (Per 10) |
| Voltage Rating | 250 V AC; 125 V DC |
| Current Rating | 30 A |
| Interrupt Rating | 200,000 A (DC) |
| Terminal Type | Ferrule |
| Response Time | 8 seconds @ 500% |
| Characteristics | Dual Element, 10 Second Time Delay |
| Dimensions – Diameter | 0.56 in |
| Dimensions – Length | 2 in |
| Product Type | Time Delay Power Fuse |
| Fuse Class | RK5 |
| Fuse Type | Ferrule |
| Connection Type | Ferrule End x Ferrule End |
| Application | General-purpose: lighting, heating, motors, transformers, inductive loads |
| Standards Met | UL Listed 248-12, Class RK-5, Guide JDDZ, File E162363; CSA C22.2 No. 248.12, Class 1422-02, File 700489; CE Certified |
| Made in USA | Yes |
| Brand | Edison |
| Model | ECNR |
| GTIN | 00782634507345 |
| Commodity Description | Dual Element Fuses |
| Category Description | Fuses & Fuse Accessories |
| Type | Class RK5 |
| Approval | UL 248-12, CE, CSA C22.2 |
