ECSR30 – 30A 600V Class RK5 Time Delay CL Fuse
$
(per )
(Each)
$24.94
(Each)
$
(per 10)
Availability:
In Stock Locally
| Attribute | Details |
|---|---|
| Catalog Number | ECSR30 Vendor Code EDN |
| Manufacturer | Edison |
| Manufacturer’s Part Number | ECSR30 |
| Description | 30A 600V Class RK5 Time Delay CL Fuse |
| Short Description | Power Fuse, 30 A, 600 VAC/300 VDC, Time Delay, RK5 Class |
| Long Description | Time Delay Power Fuse, RK5 Class Fuse, Ferrule Fuse, 10 s @ 500% Response Time, Ferrule End x Ferrule End Connection, 30 A, 600 V AC, Ferrule Terminal, 0.81 in Diameter, 5 in Overall Length, 0.50 lb |
| Extra Long Description | Class RK5 type; 5 inch; UL, CSA, CE Approval; 600 VAC Voltage Rating; 0.81 inch Diameter; 200 kAIC Interrupting Rating; 30 A Current Rating; Ferrule Terminal; Dual Element, 10 Sec Time Delay Characteristics; Applications: Branch and Feeder Circuit, AC Drive, Loadcenter, Panel Board, Switch Board, Lighting, Heating, General Purpose |
| Categories | Distribution Fuses – Dual Element |
| Classification | Fuses & Fuse Accessories |
| UNSPSC | 39121604 – Time delay fuses |
| UPC/GTIN | 782634508342 / 00782634508342 |
| Weight per Unit | 0.16 lbs (each) |
| Weight (Carton) | 0.50 lb; 0.28 kg |
| Minimum Order Quantity | 1 |
| Unit Price | $24.94 (Each) |
| Standard Packaging Price | $249.40 (Per 10) |
| Voltage Rating | 600 V AC |
| Current Rating | 30 A |
| Interrupting Rating | 200 kA (Symmetrical) |
| Response Time | 10 seconds @ 500% |
| Terminal Type | Ferrule |
| Fuse Type | Ferrule |
| Fuse Class | RK5 |
| Connection Type | Ferrule End x Ferrule End |
| Characteristics | Dual Element, 10 Sec Time Delay (at 500% Rated Load) |
| Dimensions – Diameter | 0.81 in |
| Dimensions – Length | 5 in |
| Product Type | Time Delay Power Fuse |
| Application | Branch and Feeder Circuit, AC Drive, Loadcenter, Panel Board, Switch Board, Lighting, Heating, General Purpose |
| Standards Met | UL Listed; STD. 248-12; Class RK5; Guide JDDZ, File E162363; CSA Certified; C22.2 No. 248.12; CE Certified |
| Package Quantity | 10 CT |
| Made in USA | Yes |
| Brand | Edison Fuses |
| Model | ECSR |
| Commodity Description | Dual Element Fuses |
| Category Description | Fuses & Fuse Accessories |
| Type | Class RK5 |
| Carton | 1 |
| Package | 10 |
