| Catalog Number | GHB3050 |
|---|---|
| Vendor Code | ETN |
| Manufacturer | Eaton |
| Part Number | GHB3050 |
| UPC/GTIN | 786679911297 / 00786679911297 |
Short Description: Type GHB Breaker, 3P, 50A, 277/480VAC Max, 125/250VDC Max
Long Description: Eaton Series C complete molded case circuit breaker, G-frame, GHB, complete breaker, fixed thermal, fixed magnetic trip type, three-pole, 50 A, 480Y/277 Vac, 125/250 Vdc, 50/60 Hz
Extra Long Description: ETN GHB3050 GHB CB 3P 50A 277/480VA
| Poles | 3 |
|---|---|
| Current Rating | 50 A |
| Voltage Rating | 277/480 V AC; 125/250 V DC |
| Interrupt Rating | 65 kAIC @ 240 V AC; 14 kAIC @ 480Y/277 V AC |
| Trip Type | Non-Interchangeable Thermal Magnetic |
| Mounting Type | Bolt-On |
| Frequency | 50/60 Hz |
| Frame Type | G (G-Frame) |
| Dimensions | 2.6300 in x 3.0000 in x 4.0000 in |
|---|---|
| Overall Height | 4 in |
| Overall Width | 3.8 in |
| Weight per Unit | 1.75 lb |
| Minimum Order Quantity | 1 |
|---|---|
| Unit Price | $442.37 |
| Standard Packaging | $3,538.96 (Per 8 Units) |
