(Each)
$72.51
(Each)
(per 1)
In Stock Locally
$72.51
| Field | Details |
|---|---|
| Catalog Number | IPLD2504 |
| Vendor Code | NSI |
| Manufacturer | Nsi |
| Manufacturer’s Part Number | IPLD250-4 |
| Description | 250MCM-#6 4 Pole Polaris Connector Block |
| Detailed Description | Multi-Tap Connector, #6 Awg Conductor Size, 250 MCM Conductor Size, Insulated, Plastisol Insulation Material, Copper/Aluminum Conductor Material, Black Insulation Color, 4 Conductors, -45 °C Operating Temperature, +90 °C Operating Temperature, 3.8 In Overall Length, 600 V, 0.47 LB/Ea |
| Categories | Solderless Connectors – Large Terminals & Connectors |
| Classification | Split Bolts |
| UNSPSC | 39121409 – Wire connectors |
| UPC/EAN/GTIN | 662381923028 / 6623819230280 / 00662381923028 |
| Weight per unit | 0.47 (lbs/each) |
| Minimum Order Quantity | 1 |
| Unit Price | $72.51 (Each) |
| Carton Price | $435.06 (Per 6) |
| Stock Availability | Nacogdoches: 3 (Check another store), All Stores: 813 |
| Number of Conductors | 4 |
| Poles | 1 |
| Wire Size | 250 MCM-6 AWG |
| Voltage Rating | 600 V |
| Material | Aluminum |
| Insulation Material | Plastisol |
| Conductor Material | Copper; Aluminum |
| Insulation Color | Black |
| Color | Black |
| Finish | Plastisol Insulated |
| Overall Length | 3.8 in |
| Size | L=3.800 – W=2.280 – H=2.180 |
| Product Type | Multi-Tap Connector |
| Short Description | Multi-Tap Connector, Insulated, 3.8 in L, 600 V |
| Special Features | Abrasion Resistant; Chemical Resistant; UV Resistant |
| Extra Long Description | NSI IPLD250-4 Clr 250-6AWG Insltd M |
| Features | The Polaris IPLD250-4 4-Port Dual-Sided Connector provides a simple solution for secure connection between up to four conductors. Sized for 250 MCM – 6 AWG wires and rated for 600V. Pre-insulated with oxide inhibitor, installs faster using hex key and torque wrench. Aluminum-alloy body wrapped in high-dielectric stre |
| Minimum Conductor Size | #6 AWG |
| Maximum Conductor Size | 250 MCM |
| Insulated/Non-Insulated | Insulated |
| Minimum Operating Temperature | -45 °C |
| Maximum Operating Temperature | +90 °C |
| For Use With | Wire Termination |
| Maximum Voltage Rating | 600 V |
| Standards Met | UL Listed 486B; CSA Certified; cULus Listed |
| Package Quantity | 6 CT |
| Warranty | 1 YEAR |
| Wire Type | Class B & C |
| Brand | Nsi Industries |
| Sub Brand | POLARIS(TM) |
| GTIN | 00662381923028 |
| UPC | 662381923028 |
| Category Description | SPLIT BOLTS |
| Type | Double Sided Entry |
| Packaging Weight | 0.47 lb/EA |
| Carton Quantity | 6 |
| Environmental Conditions | 90 °C |
| Temperature Rating | 90 °C |
| Standard | UL 486A/B |
| Application | Wire Termination |
