MC123BKRDWH – 12/3 WG MC Sol BK/WH/RD/GN Alu Armor 250′
$
(per )
(Each)
$1.27
(Each)
$
(per 1)
Availability:
In Stock Locally
| Field | Details |
|---|---|
| Catalog Number | MC123BKRDWH Vendor Code ALF |
| Manufacturer | Flexible Conduit |
| Manufacturer’s Part Number | 68583401 |
| Description | 12/3 WG MC Sol BK/WH/RD/GN Alu Armor 250′ Aluminum Armored Conductor, Solid, #12 AWG, PVC Jacket, Thermoplastic Nylon Insulation, Copper Conductor, 600 V, 20 A, Black, White, Red, Green, 3 Conductors, 250 ft Length, 0.505 in Diameter, +90 °C Operating Temp, 129 lb/mft |
| Slang Terms | (none provided) |
| Categories | Enhanced Commodity Codes – Wire |
| Classification | BX & MC |
| UNSPSC | 26121517 – Copper wire |
| UPC/GTIN | 032886346521 / 00032886346521 |
| Weight per unit | 0.129 lbs each |
| Price & Packaging | Minimum Order Quantity: 1 Unit Price: $1.27 (Each) Reel Price: $317.84 (Per 250 ft) |
| Features | Conductor Size: #12 AWG Current Rating: 20 A Number of Conductors: 3 Voltage Rating: 600 V |
| Material, Color, and Finish | Insulation Material: Thermoplastic Nylon Conductor Material: Copper Colors: Black, White, Red, Green Jacket Material: PVC |
| Dimensions and Weight | Overall Length: 250 ft Length: 250 ft Outside Diameter: 0.505 in |
| Descriptions | Product Type: Aluminum Armored Conductor Short Description: Aluminum Armored Conductor, Solid, 12/4 AWG with ground, PVC Jacket, 250 ft |
| Long Description | Aluminum Armored Conductor, Solid, #12 AWG, PVC Jacket, Thermoplastic Nylon Insulation, Copper Conductor, 600 V, 20 A, Black, White, Red and Green, 3 Conductors, 250 ft Length, 0.505 in Diameter, +90 °C Operating Temp, 129 lb/mft |
| Additional Information | Media: Yes Solid/Strand: Solid Maximum Operating Temperature: +90 °C |
| Standards Met | RoHS Compliant; Federal Specification A-A-59544; IEEE 1202; NEC; UL 83; UL1569; UL1685 |
| Made in USA | Yes |
| Manufacturer Information | Brand: Flexible Conduit Manufacturer’s Part Number: 68583401 GTIN: 00032886346521 UPC: 032886346521 |
| Taxonomies, Classifications, and Categories | Category Description: BX & MC Type: MC |
| Packaging | Package Type: Coil Weight: 129 lb/mft Weight per each: 0.129 Carton: 250 |
| Uses, Certifications, and Standards | Application: Commercial; Industrial; Institutional; Multi-Residential Buildings |
