(Each)
$70.12
(Each)
(per 1)
In Stock Locally
$70.12
| Catalog Number | PS5RVD24 |
|---|---|
| Vendor Code | IDC |
| Manufacturer’s Part Number | PS5RVD24 |
| Description | POWER SUPPLY 60W 24VDC DIN |
| Product Type | Power Supply |
| Short Description | Power Supply, For Industrial and Class I Division 2 Hazardous Location |
| Long Description | Power Supply, For Use In Industrial and Class I Division 2 Hazardous Locations, 0.8 A @ 230 V ac;1.3 A @ 100 V ac Input Current Rating, 100 to 370 V dc;85 to 264 V ac Input Voltage Rating, +70 °C Max Operating Temp, -25 °C Min Operating Temp, DIN Rail Mount;Panel Mount, 2.5 A Output Current Rating, 60 W Output Power, 24 V Output Voltage Rating, 108 mm Depth, 36 mm Width, CE Certified; cULus Listed; RoHS Compliant; SEMI F47 Sag Immunity; UL 508; UL1310 Class 2 Approved |
| Features | PS5R-V series combines high efficiency, compact size, improved performance, and MTBF up to 900,000 hours |
| Voltage Rating (Input) | 85 to 264 V ac; 100 to 370 V dc |
| Input Current Rating | 1.3 A @ 100 V ac; 0.8 A @ 230 V ac |
| Output Voltage Rating | 24 V |
| Output Current Rating | 2.5 A |
| Output Power | 60 W |
| Mounting Type | DIN Rail Mount; Panel Mount |
| Maximum Operating Temperature | +70 °C |
| Minimum Operating Temperature | -25 °C |
| Overall Width | 36 mm |
| Overall Depth | 108 mm |
| Standards Met | SEMI F47, RoHS, CE, cULus, UL 508, UL1310 |
| Category Description | POWER SUPPLIES |
| Classification | Power Supplies |
| UPC/EAN/GTIN | 883630122658 |
| Weight per unit | 0.57 (lbs/each) |
| Weight | 260 g |
| Minimum Order Quantity | 1 |
| Unit Price | $70.12 (Each) |
| Stock – Nacogdoches | 0 (Find nearest stock) |
| Stock – All Stores | 8 |
| Brand | IDEC CORPORATION |
| Package Quantity | 1 ct |
| Carton | 1 |
