RX62WG500 – 6/2 WG Romex-500′
$
(per )
(Each)
$2.16
(Each)
$
(per 1)
Availability:
In Stock Locally
| Field | Value |
|---|---|
| Catalog Number | RX62WG500 |
| Vendor Code | COP |
| Manufacturer | Copper |
| Manufacturer’s Part Number | 28894405 |
| Description | 6/2 WG Romex-500′ Nonmetallic-Sheathed Cable. 600 Volt. Copper Conductors. Color-Coded Jacket. Simpull Jacket Designed For Easier Pulling. |
| Slang Terms | Non-Metallic Sheathed Cable, Thermoplastic-Sheathed Cable, 220 Wire |
| Categories | Non-Metallic Cable – NM-B – NMD90 |
| Classification | Romex (RX)& Uf Cable |
| UNSPSC | 26121517 – Copper wire |
| UPC/GTIN | 032886263217 / 00032886263217 |
| Weight per unit | 0.258 (lbs/ft) |
| Price & Packaging – Minimum Order Quantity | Foot |
| Price & Packaging – Unit | $2.16 (Per Foot) |
| Price & Packaging – Reel | $1,082.24 (Per 500 Feet) |
| Stock Availability – Nacogdoches | 1,000 Feet (Check another store) |
| Stock Availability – All Stores | 193,396 Feet |
| Features – Conductor Size | #6 AWG |
| Features – Current Rating | 55 A |
| Features – Number of Conductors | 2 |
| Features – Voltage Rating | 600 V |
| Material, Color, and Finish – Conductor Material | Annealed Copper |
| Material, Color, and Finish – Jacket Material | Nylon |
| Material, Color, and Finish – Color | Black;White |
| Material, Color, and Finish – Insulation Material | PVC |
| Dimensions and Weight – Overall Length | 500 ft |
| Dimensions and Weight – Length | 3044 |
| Product Type | Nonmetallic Sheathed Cable |
| Description (Short) | 6/2 WG ROMEX-500′ |
| Features (Detailed) | Southwire Romex(R) Brand SIMpull(R) NM-B cable is manufactured as 2, 3, or 4 conductor cable, with a bare ground wire. Copper conductors are annealed (soft) copper. Stranded conductors are compressed stranded. Conductor insulation is 90°C-rated polyvinyl chloride (PVC), nylon jacketed. Romex(R) Brand SIMpull(R) NM-B cable is designed for easier pulling, resulting in easier installation. The cable jacket is color-coded for quick size identification; White – 14 AWG, Yellow – 12 AWG, Orange – 10 AWG, and Black |
| Short Description | Nonmetallic Sheathed Cable, 6/3 AWG with ground, 500 ft, Stranded |
| Additional Information | Easy Pulling |
| Extra Long Description | SWC 28894405 NMB 6/2 G 500Sp |
| Similar Brands | Romex® |
| Long Description | Nonmetallic-Sheathed Cable. 600 Volt. Copper Conductors. Color-Coded Jacket. SIMpull Jacket Designed for Easier Pulling. |
| Also Known As | Non-Metallic Sheathed Cable, Thermoplastic-Sheathed Cable, 220 Wire |
| Solid/Strand | Solid |
| Number of Strands | 7 |
| Outside Diameter | 683 x 304 mil |
| Insulation Thickness | 32 mil |
| Maximum Operating Temperature | +90 °C |
| Standards Met | NEC; Federal Specification A-A-59544; UL 83/719 |
| Made in USA | yes |
| Media | Yes |
| Strands | 1 |
| Brand | Copper |
| GTIN | 00032886263217 |
| UPC | 032886263217 |
| Category Description | ROMEX (RX)& UF CABLE |
| Packaging – Package Type | Spool |
| Weight | 255 lb/mft |
| Weight per foot | 0.258 |
| Carton | 500 |
| Application | Dry Location; Residential |
