(Each)
$2.16
(Each)
(per 1)
In Stock Locally
$2.16
| Category | Details |
|---|---|
| Catalog Number | RX62WGPCS |
| Vendor Code | COP |
| Manufacturer | Copper |
| Manufacturer’s Part Number | 63216201 |
| Description | 6/2 WG Romex-Pieces |
| Short Description | Nonmetallic Sheathed Cable, 7 Strand, 6 AWG Copper Conductor, Nylon Jacket |
| Long Description | Non-Metallic Sheathed Cable, Color-Coded Cable Jacket Additional Information, Dry Location; Residential Application, Copper Conductor Material, 6 AWG Conductor Size, 55 A Current Rating, Polyvinyl Chloride (PVC) Insulation Material, 35 mil Insulation Thickness, Nylon Jacket Material, Made in USA, +90 °C Maximum Operating Temperature, 2 – Conductors, 7 – Strands, 658 mil Overall Length, Carton Package Type, Strand Solid/Strand, ASTM B-3 and B-8; Federal Specification A-A-59544; NFPA 70; REACH/RoHS Compliant; UL |
| Slang Terms | Non-Metallic Sheathed Cable, Thermoplastic-Sheathed Cable, 220 Wire |
| Categories | Enhanced Commodity Codes – Wire |
| Classification | Romex (RX) & UF Cable |
| UNSPSC | 26121517 – Copper wire |
| UPC/GTIN | 032886999826 / 00032886999826 |
| Weight per Unit | 0.257 lbs/ft |
| Price (Per Foot) | $2.16 |
| Minimum Order Quantity | Foot |
| Reel Price | $2.16 (Per Foot) |
| Stock – Nacogdoches | 1,802 Feet |
| Stock – All Stores | 117,219 Feet |
| Conductor Size | 6 AWG |
| Voltage Rating | 600 V |
| Current Rating | 55 A |
| Number of Conductors | 2 |
| Conductor Material | Copper |
| Jacket Material | Nylon |
| Insulation Material | Polyvinyl Chloride (PVC) |
| Overall Length | 658 mil |
| Insulation Thickness | 35 mil |
| Maximum Operating Temperature | +90 °C |
| Number of Strands | 7 |
| Product Type | Non-Metallic Sheathed Cable |
| Additional Information | Color-Coded Cable Jacket; Solid/Strand; ASTM B-3 and B-8; Federal Specification A-A-59544; NFPA 70; REACH/RoHS Compliant; UL; Dry Location; Residential Application |
| Standards Met | UL 719; UL 83; ASTM B-3 and B-8; Federal Specification A-A-59544; NFPA 70; REACH/RoHS Compliant |
| Made in USA | Yes |
| Brand | Copper |
| Carton | 1 |
| Weight | 252 lbs/1000 ft |
| Taxonomies, Classifications | ROMEX (RX) & UF CABLE |
| Packaging | Carton |
| Application | Dry Location; Residential |
