Description
$3,831.40
Description
Field | Details |
---|---|
Catalog Number | RX82WG2500 |
Vendor Code | COP |
Manufacturer | Copper |
Manufacturer’s Part Number | 28893608 |
Description | 8/2 WG Romex-2500′ |
Voltage Rating | 600 V |
Conductor Material | Annealed Copper |
Insulation Material | PVC |
Jacket Material | Nylon |
Color | Black; White |
Number of Conductors | 2 |
Conductor Size | #8 AWG |
Current Rating | 40 A |
Overall Length | 2500 ft |
Length | 2692 |
Weight per foot | 0.189 lbs/ft |
Weight | 186 lb/1000 ft |
Minimum Order Quantity | 2,500 Feet |
Unit Price | $1.53 (Per Foot) |
Reel Price | $3,831.40 (Per 2,500 Feet) |
Stock Availability (Nacogdoches) | 2,500 Feet |
Stock Availability (All Stores) | 119,714 Feet |
Number of Strands | 7 |
Strands | 1 |
Outside Diameter | 612 x 269 mil |
Insulation Thickness | 35 mil |
Maximum Operating Temperature | +90 °C |
Solid/Strand | Solid |
Standards Met | NEC; Federal Specification A-A-59544; UL 83/719 |
Made in USA | Yes |
Slang Terms | Non-Metallic Sheathed Cable, Thermoplastic-Sheathed Cable, 220 Wire |
Categories | Non-Metallic Cable – NM-B – NMD90 |
Classification | Romex (RX) & UF Cable |
UNSPSC | 26121517 – Copper wire |
UPC/GTIN | 032886263309 / 00032886263309 |
Product Type | Nonmetallic Sheathed Cable |
Short Description | Nonmetallic Sheathed Cable, 8/3 AWG with ground, 2500 ft, Stranded |
Features | Southwire Romex® Brand SIMpull® NM-B cable; 2, 3 or 4 conductor cable with bare ground; annealed copper conductors; 90°C-rated PVC insulation with nylon jacket; color-coded jacket for easy ID; SIMpull technology for easier pulling |
Additional Information | Easy Pulling |
Long Description | Nonmetallic-Sheathed Cable. 600 Volt. Copper Conductors. Color-Coded Jacket. SIMpull Jacket Designed for Easier Pulling. |
Packaging | Reel |
Carton | 2500 |
Application | Dry Location; Residential |
Media | Yes |
Brand | Copper |
Type | ROMEX (RX) & UF Cable |
Availability | Minimum quantity 2500 |
