(Each)
$3,751.02
(Each)
(per 1)
In Stock Locally
$3,751.02
| Field | Details |
|---|---|
| Catalog Number | TC83WG1000 Vendor Code COP |
| Manufacturer | Copper |
| Manufacturer’s Part Number | 44339002 |
| Description | 8/3 WG Tray Cable-1000′ |
| Product Type | Tray Cable |
| Short Description | Tray Cable, 7 Strands, 8 AWG, 1000 ft |
| Long Description | TCP 8/3 Cu 600V PN 1x10CG PVC Bk 1000R |
| Extra Long Description | SWC 44339002 TCP 8/3 Cu 600V PN 1×1 |
| Features | Southwire’s Type TC Power Cable with THHN/THWN conductors; flame retardant, moisture and sunlight resistant PVC jacket; non-halogen jacket available on request |
| Conductor Size | #8 AWG |
| Number of Conductors | 3 |
| Number of Strands | 7 |
| Voltage Rating | 600 V |
| Conductor Material | Copper |
| Insulation Material | PVC; Nylon |
| Jacket Material | PVC |
| Overall Length | 1000 ft |
| Weight per unit | 0.295 lbs/ft |
| Price & Packaging | Minimum Order Quantity: 1,000 Feet; Unit Price: $3.75 per Foot; Reel Price: $3,751.02 per 1,000 Feet |
| Stock Availability | Nacogdoches: 0 Feet (Find nearest stock); All Stores: 53,830 Feet |
| UPC/GTIN | 032886064784 / 00032886064784 |
| Standards Met | ASTM; UL 1277; ICEA S-58-679; UL 1685; ICEA T-29-520; IEEE 1202/FT4; ICEA S-95-658; UL 1581; RoHS Compliant; ICEA S-58-679 |
| Maximum Operating Temperature | +75 °C (Wet); +90 °C (Dry) |
| Outside Diameter | 0.625 in |
| Solid/Strand | Stranded |
| Applications | Utility Substations; Indoors or Outdoors; Cable Trays; Conduit; Underground Duct or Direct Buried in Wet or Dry Locations |
| Made in USA | Yes |
| Media | Yes |
| Category Description | TRAY CABLE |
| Packaging | Reel; Carton |
| Carton Size | 1,000 Feet |
| Brand | Copper |
