(Each)
$140.23
(Each)
(per 1)
(per 1000)
In Stock Locally
$140.23
| Attribute | Value |
|---|---|
| Catalog Number | THHN10S0LWH500 |
| Vendor Code | COP |
| Manufacturer | Copper |
| Manufacturer’s Part Number | 55154503 |
| Description | THHN 10 Sol White 500′ |
| Voltage Rating | 600 V |
| Current Rating | 30 A |
| Conductor Size | #10 AWG |
| Number of Conductors | 1 |
| Conductor Material | Annealed Copper |
| Jacket Material | Nylon |
| Insulation Material | PVC |
| Color | White (Insulation) |
| Overall Length | 500 ft |
| Length | 500 ft |
| Outside Diameter | 150 mil |
| Insulation Thickness | 20 mil |
| Weight per Foot | 0.037 lbs/ft |
| Weight (lb/mft) | 36 lb/mft |
| Minimum Order Quantity | 500 Feet |
| Unit Price | $0.28 (Per Foot) |
| Reel Price | $140.23 (Per 500 Feet) |
| Standard Packaging Price | $280.46 (Per 1,000 Feet) |
| Category | Copper Building Wire – THHN-T90-Sol (Solid) |
| Classification | Building Wire |
| UNSPSC | 26121517 – Copper wire |
| UPC/GTIN | 032886225109 / 00032886225109 |
| Product Type | THHN Copper Building Wire |
| Short Description | THHN Copper Building Wire, #10 AWG, Solid, Yellow, 500 |
| Extra Long Description | SWC 11596401 THHN 10 Sol Cu We 500S |
| Long Description | 600 Volts. Copper Conductor. Thermoplastic Insulation/Nylon Sheath, Heat, Moisture, Gasoline and Oil Resistant II. Rated THHN and THWN. Also rated AWM. |
| Features | Heat Resistant; Moisture Resistant; SIMpull® Technology |
| Maximum Operating Temperature | +90 °C |
| Standards Met | RoHS, ASTM B3, B8, B787; UL 83, 758, 1063, 1581; CSA C22.2; NFPA 70; NEMA WC-70; Federal Specification A-A-59544 |
| Made in USA | Yes |
| Application | Building; Commercial; Industrial |
| Media | Yes |
| Package Type | Spool |
| Carton | 500 |
| Package | 1000 |
