| Field | Value |
|---|---|
| Catalog Number | THHN1GNPCS |
| Vendor Code | COP |
| Manufacturer | Copper |
| Manufacturer’s Part Number | 64766305 |
| Description | THHN 1 STR GREEN PCS |
| Product Type | THHN Building Wire |
| Short Description | THHN Building Wire, 600 V, Green, Nylon Jacket, 19 Strands, 1 AWG |
| Long Description | THHN Building Wire, Heat, Moisture, Gasoline and Oil Resistant; SIMpull® Technology; Sunlight Resistant. Commercial & Industrial Use. Green Color, Copper Conductor, 1 AWG, 110 A (60°C); 130 A (75°C); 145 A (90°C), PVC Insulation (50 mil), Nylon Jacket, Made in USA, 19 Strands, 435 mil OD. |
| Extra Long Description | SWC 64766305 Weld 4/0 Cu CPE Oe UL |
| Application | Commercial; Industrial |
| Voltage Rating | 600 V |
| Current Rating | 110 A (60°C); 130 A (75°C); 145 A (90°C) |
| Conductor Size | 1 AWG |
| Number of Conductors | 1 |
| Number of Strands | 19 |
| Strands | 5320 |
| Conductor Material | Copper |
| Jacket Material | Nylon |
| Insulation Material | PVC |
| Insulation Thickness | 50 mil |
| Outside Diameter | 435 mil |
| Color | Green |
| Maximum Operating Temp | +90 °C |
| Standards Met | CSA C22.2 No. 75; UL 83, 758, 1063, 1581; NOM-ANCE 90°C; Federal Spec A-A-59544; NEMA WC-70 (ICEA S-95-658); NEC (NFPA 70); FT1; MTW; RoHS/REACH; ASTM B3, B8, B787; VW-1; UL Listed; cULus Listed |
| Made in USA | Yes |
| Weight per Foot | 0.3 lbs/ft |
| Weight (1000 ft) | 299 lbs |
| UPC | 032886999147 |
| GTIN | 00032886999147 |
| Minimum Order Quantity | Foot |
| Unit Price | $2.61/ft |
| Reel Price | $2.61/ft |
| Stock Availability – Nacogdoches | 0 Feet |
| Stock Availability – All Stores | 56,565 Feet |
| Classification | Building Wire |
| Category Description | BUILDING WIRE |
| Type | 4/0 |
| Packaging Type | Reel; Spool |
| Carton | 1 |
