(Each)
$10.10
(Each)
(per 1)
In Stock Locally
$10.10
| Field | Details |
|---|---|
| Catalog Number | THHN350BRPCS |
| Vendor Code | COP |
| Manufacturer | Copper |
| Manufacturer’s Part Number | 95306702 |
| Description | THHN 350 STR Brown PCS THHN Building Wire, Heat, Moisture, Gasoline and Oil Resistant; SIMpull® Technology For Easier Pulling; Sunlight Resistant; Commercial/Industrial Application; Brown; Copper Conductor Material; 350 kcmil Conductor Size; Current Rating: 260 A (60°C), 310 A (75°C), 350 A (90°C); PVC Insulation; 60 mil Insulation Thickness; Nylon Jacket; Made in USA; Max Operating Temp: +90 °C; 37 Strands; 797 mil Outside Diameter; Reel/Spool Package Type |
| Slang Terms | – |
| Categories | Enhanced Commodity Codes – Wire |
| Classification | Building Wire |
| UNSPSC | 26121517 – Copper wire |
| UPC/GTIN | 032886998638 / 00032886998638 |
| Weight per unit | 1.174 lbs/ft |
| Price & Packaging | Minimum Order Quantity: Foot Unit Price: $10.10 (Per Foot) Reel Price: $10.10 (Per Foot) |
| Stock Availability | Nacogdoches: 0 Feet (Find nearest stock) All Stores: 39,695 Feet |
| Features | Current Rating: 260 A (60°C), 310 A (75°C), 350 A (90°C) Voltage Rating: 600 V Conductor Size: 350 kcmil |
| Material, Color, and Finish | Jacket Material: Nylon Insulation Material: PVC Conductor Material: Copper Color: Brown |
| Descriptions | Product Type: THHN Building Wire Long Description: THHN Building Wire, Heat, Moisture, Gasoline and Oil Resistant; SIMpull® Technology for Easier Pulling; Sunlight Resistant; Commercial/Industrial Application; Brown; Copper Conductor Material; 350 kcmil Conductor Size; Current Ratings as above; PVC Insulation; 60 mil Insulation Thickness; Nylon Jacket; Made in USA; Max Temp +90°C; 37 Strands; 797 mil Outside Diameter; Reel/Spool Package Type |
| Features (continued) | Soft drawn copper, combination-unilay stranding for sizes 14-4/0 AWG, compressed copper for 250 kcmil and larger, tough heat/moisture resistant PVC insulation, SIMpull® Technology, multiple colors and striped configurations available |
| Short Description | THHN Building Wire, 600 V, Brown, Nylon Jacket, 37 Strands, 350 kcmil |
| Additional Information | Heat, Moisture, Gasoline and Oil Resistant; SIMpull® Technology for Easier Pulling; Sunlight Resistant |
| Extra Description | SWC 95306702 TCC 12-7 4C Cu 600V XL |
| Number of Strands | 37 |
| Standards Met | CSA C22.2 No. 75; UL Standards 83, 758, 1063, 1581; NOM-ANCE 90°C; Federal Specification A-A-59544; NEMA WC-70; NFPA 70; FT1 – All Sizes; MTW – Stranded Only; RoHS/REACH Compliant; UL Listed; cULus Listed; CT Rated |
| Outside Diameter | 797 mil |
| Insulation Thickness | 60 mil |
| Maximum Operating Temperature | +90 °C |
| Made in USA | Yes |
| Manufacturer Information | Brand: Copper Manufacturer’s Part Number: 95306702 GTIN: 00032886998638 UPC: 032886998638 |
| Taxonomies, Classifications, and Categories | Category Description: BUILDING WIRE |
| Packaging | Package Type: Reel; Spool Carton: 1 |
| Weight | 1174 lbs per 1000 ft |
| Weight per foot | 1.174 lbs/ft |
| Uses, Certifications, and Standards | Application: Commercial; Industrial |
