(Each)
$6.21
(Each)
(per 1)
In Stock Locally
$6.21
| Field | Details |
|---|---|
| Catalog Number | THHN40BKPCS |
| Vendor Code | COP |
| Manufacturer | Copper |
| Manufacturer’s Part Number | 63216301 |
| Description | THHN 4/0 STR Black PCS |
| Long Description | THHN Building Wire, Heat, Moisture, Gasoline and Oil Resistant; SIMpull(R) Technology For Easier Pulling; Sunlight Resistant. Commercial; Industrial Application, Black, Copper Conductor Material, 4/0 AWG Conductor Size, 195 A (60°C); 230 A (75°C); 260 A (90°C) Current Rating, PVC Insulation Material, 50 Mil Insulation Thickness, Nylon Jacket Material, Made In USA, +90 °C Maximum Operating Temperature, 19 Strands, 624 Mil Outside Diameter, Reel/Spool Package Type, CSA C22.2 No. 75; Federal… |
| Slang Terms | |
| Categories | Enhanced Commodity Codes – Wire |
| Classification | Building Wire |
| UNSPSC | 26121517 – Copper wire |
| UPC/GTIN | 032886999840 / 00032886999840 |
| Weight per Unit | 0.717 (lbs/ft) |
| Price & Packaging | |
| Minimum Order Quantity | Foot |
| Unit Price | $6.21 (Per Foot) |
| Reel Price | $6.21 (Per Foot) |
| Stock Availability | |
| Nacogdoches | 5,697 Feet (Check another store) |
| All Stores | 191,022 Feet |
| Features | |
| Current Rating | 195 A (60°C); 230 A (75°C); 260 A (90°C) |
| Voltage Rating | 600 V |
| Conductor Size | 4/0 AWG |
| Jacket Material | Nylon |
| Insulation Material | PVC |
| Conductor Material | Copper |
| Color | Black |
| Product Type | THHN Building Wire |
| Short Description | THHN Building Wire, 600 V, Black, Nylon Jacket, 19 Strands, 4/0 AWG |
| Additional Information | Heat, Moisture, Gasoline and Oil Resistant; SIMpull(R) Technology for Easier Pulling; Sunlight Resistant |
| Number of Strands | 19 |
| Outside Diameter | 624 mil |
| Insulation Thickness | 50 mil |
| Maximum Operating Temperature | +90 °C |
| Standards Met | CSA C22.2 No. 75; UL Standards 83, 758, 1063, 1581; NOM-ANCE 90° C; Federal Specification A-A-59544; NEMA WC-70 (ICEA S-95-658); NEC NFPA 70; FT1 – All Sizes; MTW – Stranded Constructions Only; RoHS/REACH Compliant; ASTM B3, B8, B787; UL Listed; cULus Listed; CT Rated |
| Made in USA | Yes |
| Tip Size | By-the-foot |
| Brand | Copper |
| Packaging Package Type | Reel; Spool |
| Weight | 718 lb/1000 ft |
| Weight per Foot | 0.717 |
| Carton | 1 |
| Application | Commercial; Industrial |
