TV18BSXV – 22-16 Butt Splice
$
(per )
(Each)
$0.55
(Each)
$
(per 1)
$
(per 900)
Availability:
In Stock Locally
| Field | Details |
|---|---|
| Catalog Number | TV18BSXV |
| Vendor Code | TAB |
| Manufacturer | Catamount |
| Manufacturer’s Part Number | TV18-BS-XV |
| Description | 22-16 Butt Splice |
| Product Type | Butt Splice Connector |
| Conductor Size Range | #22 AWG to #18 AWG |
| Insulation | Insulated, Vinyl Insulation Material |
| Conductor Material | Copper (Tin Plated) |
| Insulation Color | Red |
| Terminal Type | Compression Terminal |
| Voltage Rating | 600 V AC |
| Operating Temperature | Up to 75 °C |
| Overall Length | 0.986 in |
| Outer Diameter | 0.157 in |
| Inner Diameter | 0.067 in |
| Weight per unit | 0.005 lbs |
| Price & Packaging | Minimum Order Quantity: 1Unit Price: $0.55 (Each)Carton Price: $41.47 (Per 75)Standard Packaging: $497.61 (Per 900) |
| Stock Availability | Nacogdoches: 915 (Check other stores)All Stores: 2,325 |
| Special Features | Expanded Entry, Brazed Seams, Internal Barrel Serrations |
| Standards Met | UL Listed E9809; CSA Certified |
| Made in USA | Yes |
| Packaging Quantities | 15 per pack, 75 per carton, 900 per package |
