(Each)
$558.20
(Each)
(per 1)
In Stock Locally
$558.20
| Field | Value |
|---|---|
| Catalog Number | U17970K3LK2L |
| Vendor Code | MIB |
| Manufacturer | Milbank |
| Manufacturer’s Part Number | U1797-O-K3L-K2L |
| Description | 320A 1PH UG 4T LVR BYPASS METER SOCKET |
| Product Type | Meter Socket |
| Short Description | Meter Socket, 320 A, 600VAC, #4 AWG to 600 kcmil;1/0 AWG to 250 kcmil;#6 AWG to 350 kcmil |
| Long Description | Meter Socket, 320 A, 30 in Overall Height, 15 in Overall Width, 4-7/8 in Overall Length, Surface Mount, 1 Phase, Plain Top Hub, 4 Jaws, 4 Wires, 600 V AC, #4 AWG to 600 kcmil;1/0 AWG to 250 kcmil;#6 AWG to 350 kcmil Wire Size, Underground Feed, 32.4 lb |
| Extra Long Description | MILB U1797-O-K3L-K2L 320A 4T RL SWY |
| Category | Single Meter Sockets – Residential Single Meter Socket |
| Classification | Meter Sockets |
| UNSPSC | 39121102 – Meter centers or sockets |
| UPC/GTIN | 784572301726 / 00784572301726 |
| Weight | 32.4 lb |
| Minimum Order Quantity | 1 |
| Unit Price | $558.20 (Each) |
| Current Rating | 320 A |
| Voltage Rating | 600 V AC |
| Number of Phases | 1 Phase |
| Number of Wires | 4 |
| Wire Size | #4 AWG to 600 kcmil; 1/0 AWG to 250 kcmil; #6 AWG to 350 kcmil |
| Mounting Type | Surface Mount |
| Enclosure Type | NEMA 3R |
| Enclosure Material | G90 Galvanized Steel with Powder Coat Finish |
| Hub Type | Plain Top |
| Bypass Type | Lever Bypass |
| Feed Type | Underground |
| Cutout Size | No Main Breaker |
| Application | Meter Socket |
| Frequency Rating | 60 Hertz |
| Number of Jaws | 4 |
| Dimensions (L x W x H) | 4.844 in x 15 in x 30 in |
| Standard | UL Listed |
| Type | Ringless Meter Socket |
